- General Information
- Manufacturer
- Axis Communications
- Manufacturer Website Address
- http://www.axis.com
- Brand Name
- AXIS
- Product Series
- Q36
- Product Type
- Network Camera
- Technical Information
- HD Recording
- Yes
- Display & Graphics
- Image Sensor Type
- CMOS
- Image Sensor Size
- 1/1.8"
- Color Supported
- Color
- Field of View
- Horizontal field of view: 103°-52° Vertical field of view: 56°-30°
- Effective Camera Resolution
- 4 Megapixel
- Video
- Video Formats
- Zipstream
- Motion JPEG
- H.264 (MPEG-4 Part 10/AVC)
- H.265 (MPEG-H Part 2/HEVC)
- Maximum Video Resolution
- 2688 x 1512
- Maximum Frame Rate
- 60 fps
- Lens
- Lens Type
- Varifocal
- Minimum Focal Length
- 4.30 mm
- Maximum Focal Length
- 8.60 mm
- Lens Included
- Yes
- Minimum Aperture
- f/2.4
- Maximum Aperture
- f/1.5
- Optical Zoom
- 2x
- Exposure
- Shortest Shutter Speed
- 1/91000 Second
- Longest Shutter Speed
- 1 Second
- Network & Communication
- Connectivity Technology
- Wired
- Ethernet Technology
- Gigabit Ethernet
- Protocols
- IPv4
- IPv6 USGv6
- ICMPv4/ICMPv6
- HTTP
- HTTPS
- TLS
- FTP
- SFTP
- SMTP
- SNMP (v1/v2c/v3)
- DNSv6
- DNS
- NTP
- RTSP
- IGMPv1/v2/v3
- DHCPv4/v6
- LLDP
- MQTT
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Input Voltage
- 28 V DC
- Power Source Type
- DC
- PoE
- Physical Characteristics
- Form Factor
- Dome
- Color Family
- White
- Product Color
- White
- Height
- 5.6"
- Diameter
- 7.2"
- Weight (Approximate)
- 4.63 lb
- Environmental Conditions
- Minimum Operating Temperature
- -58°F (-50°C)
- Maximum Operating Temperature
- 131°F (55°C)
- Maximum Operating Humidity
- 100%
- Miscellaneous
- Features
- Back Light Compensation (BLC)
- Highlight Compensation (HLC)
- Wide Dynamic Range
- 3D Digital Noise Reduction
- Noise Detection
- Mirror
- Password Protection
- Cross Line Detection
- Vehicle Detection
- Human Detection
- Motion Detection
- Impact Protection Rating
- IK10
- Ingress Protection Rating
- IP66
- IP6K9K
- Country of Origin
- Cambodia
- TAA Compliant
- Yes
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
